Imagine listening to your favorite music or an important podcast in a busy café, without headphones and without disturbing anyone around you. Or having a private conversation in a public park, where only you and your listener can hear the words, while others remain uninterrupted and unaware of your conversation.
Penn State University’s new innovative targeted audio technology promises to make this futuristic dream into a reality. Known as audible enclaves, this targeted audio technology may completely revolutionize how we experience sound in shared spaces. By using ultrasound waves and advanced acoustic engineering, researchers have developed a system that delivers audio exclusively to a single listener without headphones. This targeted audio technology does this by creating localized pockets of sound that are audible only at precise locations and even in crowded spaces. This innovation could redefine privacy, accessibility, and noise control in public and private settings.
Why Controlling Sound Is Difficult
Sound is a vibration that disrupts the air and travels through it as waves. These waves are created when objects, particularly speakers, oscillate or move back and forth, compressing and decompressing air molecules. The frequency of these vibrations determines the pitch we hear; low frequencies produce deep sounds like a bass drum, while high frequencies produce sharp sounds like a whistle.
However, controlling where sound goes is quite difficult because of a phenomenon called diffraction. As sound waves travel, they tend to spread out, especially at lower frequencies where wavelengths are longer. This spreading makes it almost impossible to confine sound to a small area using traditional speakers.
Existing technologies like parametric array loudspeakers attempt to focus sound beams in a particular direction, but even these emit audible sound along the entire path of the beam. This means people standing anywhere along that path can hear the sound, which limits privacy and control. However, Penn State University’s targeted audio technology promises to mitigate these limitations, offering a fundamentally new approach to delivering sound precisely where it is needed.
Ultrasound and Nonlinear Acoustics
The important mechanisms in this targeted audio technology is the use of ultrasound waves which are sound waves with frequencies above 20,000 Hz. These frequencies are inaudible to human ears. Ultrasound is commonly used in medical imaging and industrial applications. This is because it can travel through air silently and interact with objects in unique ways. Initially, they used the ultrasound waves as a carrier for the audible sound to transport the sound through space and then becoming audible when desired.
The Penn State researchers did this using two beams of ultrasound at slightly different frequencies, for example, 40,000 Hz and 39,500 Hz. Individually, these beams are completely silent to human ears. When these beams intersect, nonlinear interactions in the air generate a new sound wave at the difference frequency (500 Hz in this example), which falls within the human hearing range.
This process, called difference frequency generation, allows the creation of audible sound only at the precise point where the ultrasound beams cross each other. Outside of this intersection, the ultrasound waves remain silent and undetectable. To visualize this, imagine two invisible beams of sound crossing in midair, producing a tiny bubble of audible sound that only a person standing exactly at that spot can hear. Move away just a few inches, and the sound disappears.
Acoustic Metasurfaces Enable Precision Targeting
Normally, sound waves travel in straight lines unless they hit an obstacle or reflect off surfaces. This limits the ability to deliver sound to a listener who is not directly in line with the speaker. To mitigate this from happening, the Penn State team developed acoustic metasurfaces. Using acoustic metasurfaces, which are specially engineered materials that change the shape of the path of the sound waves.
By controlling the phase of the ultrasound waves, they can create curved sound paths, helping beams curve around obstacles like human heads or furniture, ensuring sound reaches its target. The system operates between 125 Hz and 4 kHz, covering most speech and music tones.
Potential Applications of Targeted Audio Technology
Targeted audio technology offers many potential applications across diverse environments. Museums, galleries, and libraries can use these audible enclaves to deliver personalized audio guides directly to visitors without headphones. This would allow individuals to hear exhibit narrations without disturbing others nearby. In open environments like offices, airports, and public parks, the technology can create private “speech zones” that enable confidential conversations. This could mitigate issues of risk of eavesdropping, benefiting business meetings, medical consultations, and military communications.
In vehicles, passengers can enjoy music or podcasts through audible enclaves without distracting the driver, who can focus on navigation instructions and emergency alerts. Urban areas suffering from noise pollution can deploy these audible enclaves to establish quiet zones, selectively canceling unwanted noise. For entertainment venues such as theme parks, theaters, and gaming arenas, targeted audio technology can be used to craft immersive sound experiences for audiences.
Targeted Audio Technology Challenges in Commercialization
While targeted audio technology holds immense promise, researchers need to address several technical limitations before it can be implemented in the mainstream sphere. One of the primary challenges is sound quality. Nonlinear interactions between ultrasound beams can introduce distortion, particularly for complex audio like music. Researchers have set their focus on refining signal processing techniques to enhance clarity and fidelity. By drawing on advances in digital signal processing and even deep learning, researchers aim to isolate and deliver cleaner target audio.
Generating the intense ultrasound fields required for audible enclaves demands substantial power, which can be energy-intensive. Range and volume also limit current systems. Present prototypes operate effectively at distances of about three feet and at moderate volumes similar to a conversation. Finally, dynamic targeting is essential for real-world applications. Future systems will need to track listeners as they move and adjust the paths of the audio beams in real time.
Despite these challenges, targeted audio technology represents a fundamental shift in how we control and deliver sound. Continued innovation will overcome these obstacles, paving the way for personalized, precise, and immersive audio experiences.
Redefining Our Relationship with Sound
Penn State’s targeted audio technology shows promise in revolutionising sound control by overcoming the problem of diffraction and sound leakage. By using ultrasound, nonlinear acoustics, and acoustic metasurfaces, audible enclaves create private, localized audio experiences that could integrate into daily life. While commercialization may still be years away, the potential applications, from museums to cars, offices to cities, are truly exciting. This technology promises to silence the noise of the modern world, replacing it with sound that respects both individual privacy and collective peace.
